Material: el metal externo es de acero inoxidable 304; el sello es de caucho modificado; la manga del núcleo es PA6, la funda es de hierro galvanizado / acero inoxidable
Manga de sellado: TPE
Nivel de protección: IP65
Rango de temperatura: -40 ° C a 100 ° C, puede alcanzar +120 ° C en poco tiempo
|
Modelo Item No . |
Tamaño del hilo Thread mm |
Rango de bayoneta clamping mm |
Longitud del hilo GL mm |
Tamaño de la llave Wrench size mm |
Manguera adaptadora (diámetro interior nominal) Fits to tubing size (Nominal inner） mm |
Embalaje Std.Pkg PCS |
| NBLS-M con conector de manguera de metal de bloqueo | ||||||
| NBLS -01M | M12x1.5 | 3-5.5 | 6 | 18/17/14 | φ6 | 25 |
| NBLS -02M | M16x1.5 | 4-7 | 7 | 20/19/18 | φ8 | 25 |
| NBLS -03M | M18x1.5 | 5-9 | 7 | 24/23/20 | φ10 | 25 |
| NBLS -04M | M20x1.5 | 6-11 | 7 | 26/26/22 | φ13 | 25 |
| NBLS -05M | M20x1.5 | 6-12 | 7 | 30/28/24 | φ16 | 25 |
| NBLS -05M | M22x1.5 | 8-14 | 7 | 30/30/24 | φ16 | 25 |
| NBLS -05M | M24x1.5 | 8-14 | 7 | 30/30/27 | φ16 | 25 |
| NBLS -05M | M25x1.5 | 8-14 | 7 | 30/30/28 | φ16 | 25 |
| NBLS -06M | M25x1.5 | 13-18 | 7 | 36/34/30 | φ20 | 25 |
| NBLS -06M | M32x1.5 | 13-18 | 8 | 36/34/36 | φ20 | 10 |
| NBLS -08M | M32x1.5 | 15-22 | 8 | 45/40/36 | φ25 | 10 |
| NBLS -08M | M36x2.0 | 15-22 | 8 | 45/45/40 | φ25 | 10 |
| NBLS -10M | M40x1.5 | 22-30 | 9 | 55/52/45 | φ32 | 5 |
| NBLS -10M | M48x2.0 | 22-30 | 9 | 55/52/55 | φ32 | 5 |
| NBLS -12M | M40x1.5 | 22-32 | 9 | 60/58/50 | φ38 | 5 |
| NBLS -12M | M50x1.5 | 30-35 | 9 | 60/58/55 | φ38 | 5 |
| NBLS -12M | M56x2.0 | 30-35 | 9 | 60/58/60 | φ38 | 2 |
| NBLS -16M | M50x1.5 | 30-38 | 9 | 75/75/75 | φ51 | 2 |
| NBLS -16M | M60x1.5 | 37-44 | 10 | 75/75/70 | φ51 | 2 |
| NBLS-P con conector de manguera de acero inoxidable con bloqueo | ||||||
| NBLS -02P | PG7 | 3-5.5 | 6 | 18/17/14 | φ6 | 25 |
| NBLS -03P | PG9 | 4-7 | 7 | 20/19/17 | φ8 | 25 |
| NBLS -04P | PG11 | 5-9 | 7 | 24/23/20 | φl0 | 25 |
| NBLS -05P | PG13.5 | 6-11 | 7 | 26/26/22 | φl2 | 25 |
| NBLS -05P | PG16 | 8-14 | 7 | 30/30/24 | φl5 | 25 |
| NBLS -06P | PG21 | 13-18 | 8 | 36/34/30 | φ20 | 10 |
| NBLS -08P | PG29 | 15-22 | 8 | 45/45/40 | φ25 | 10 |
| NBLS -12P | PG36 | 22-30 | 9 | 55/52/50 | φ32 | 5 |
| NBLS -15P | PG42 | 30-35 | 9 | 60/58/58 | φ38 | 5 |
| NBLS -16P | PG48 | 37-44 | 10 | 75/75/65 | φ38 | 2 |
