型号 Item No . |
螺纹规格 |
螺纹外径 |
螺纹长度 |
内孔径 |
外径 |
长度 |
|
|
黑色 Black |
深灰色Gray |
||||||
| 公制螺纹 MBGW-M | |||||||
| MBGW-M12B(BG07) | MBGW-M12G(BG07) | M12×1.5 | 12.0 | 10.0 | 8.5 | 17.0 | 33.5 |
| MBGW-M16B(BG10) | MBGW-M16G(BG10) | M16×1.5 | 16.0 | 10.0 | 12.0 | 20.0 | 36.0 |
| MBGW-M16B(BG12) | MBGW-M16G(BG12) | M16×1.5 | 16.0 | 10.0 | 12.0 | 23.0 | 42.0 |
| MBGW-M18B(BG12) | MBGW-M18G(BG12) | M18×1.5 | 18.0 | 10.0 | 15.5 | 23.0 | 42.0 |
| MBGW-M20B(BG12) | MBGW-M20G(BG12) | M20×1.5 | 20.0 | 10.0 | 15.5 | 23.0 | 42.0 |
| MBGW-M20B(BG15) | MBGW-M20G(BG15) | M20×1.5 | 20.0 | 11.0 | 13.5 | 26.5 | 46.0 |
| MBGW-M20B(BG17) | MBGW-M20G(BG17) | M20×1.5 | 20.0 | 12.0 | 14.8 | 29.5 | 50.0 |
| MBGW-M22B(BG17) | MBGW-M22G(BG17) | M22*1.5 | 22.0 | 12.0 | 18.0 | 29.5 | 59.0 |
| MBGW-M24B(BG17) | MBGW-M24G(BG17) | M24×1.5 | 24.0 | 13.0 | 18.0 | 29.5 | 50.0 |
| MBGW-M25B(BG17) | MBGW-M25G(BG17) | M25×1.5 | 25.0 | 13.0 | 14.8 | 29.0 | 46.0 |
| MBGW-M25B(BG23) | MBGW-M25G(BG23) | M25×1.5 | 25.0 | 13.0 | 18.0 | 29.0 | 50.0 |
| MBGW-M32B(BG29) | MBGW-M32G(BG29) | M32×1.5 | 32.0 | 15.0 | 24.0 | 44.0 | 67.5 |
| MBGW-M40B(BG36) | MBGW-M40G(BG36) | M40×1.5 | 40.0 | 15.0 | 32.0 | 52.0 | 83.0 |
| MBGW-M50B(BG48) | MBGW-M50G(BG48) | M50×1.5 | 50.0 | 16.0 | 39.0 | 64.0 | 88.0 |
| MBGW-M63B(BG48) | MBGW-M63G(BG48) | M63×1.5 | 63.0 | 16.0 | 53.0 | 64.0 | 88.0 |
| 德制螺纹 MBGW-P | |||||||
| MBGW-PG7B(BG07) | MBGW-PG7G | PG7 | 12.5 | 10.0 | 8.5 | 17.0 | 33.5 |
| MBGW-PG9B(BG10) | MBGW-PG9G | PG9 | 15.2 | 10.0 | 12.0 | 20.0 | 36.0 |
| MBGW-PG11B(BG12) | MBGW-PG11G | PG11 | 18.6 | 10.0 | 12.0 | 23.0 | 42.0 |
| MBGW-PG13.5B(BG15) | MBGW-PG13.5G | PG13.5 | 20.4 | 11.0 | 13.5 | 26.5 | 46.0 |
| MBGW-PG13.5B(BG17) | MBGW-PG13.5G | PG13.5 | 20.4 | 12.0 | 18.0 | 29.5 | 50.0 |
| MBGW-PG16B(BG17) | MBGW-PG16G | PG16 | 22.5 | 12.0 | 18.0 | 29.5 | 50.0 |
| MBGW-PG21B(BG23) | MBGW-PG21G | PG21 | 28.3 | 12.0 | 24.0 | 37.0 | 57.0 |
| MBGW-PG29B(BG29) | MBGW-PG29G | PG29 | 37.0 | 12.0 | 32.0 | 44.0 | 67.5 |
| MBGW-PG36B(BG36) | MBGW-PG36G | PG36 | 47.0 | 12.0 | 36.0 | 52.0 | 83.0 |
| MBGW-PG42B(BG48) | MBGW-PG42G | PG42 | 54.0 | 14.0 | 48.0 | 64.0 | 88.0 |
| MBGW-PG48B(BG48) | MBGW-PG48G | PG48 | 59.3 | 14.0 | 48.0 | 64.0 | 88.0 |
